Description
Specifications:
General
Gray colored
Unshielded Twisted 4-Pair
23 AWG
Stranded core
PVC jacket
Meets or exceeds Cat6 specifications
Rated to 250 MHz
Ideal for for carrying data, audio and video
Flame retardant rating: CM
In-wall rated; permitted in 1-2 family residential riser applications, or in riser with raceway/fireproof shaft; not permitted in plenums
UL approved
Technical:
TIA Cat6 channel test 250 MHz:
Return loss (db) = 17.32
Attenuation (db/100) = 33.04
Near-end crosstalk (db) = 38.3
Power sum-NEXT (db) = 36.3
Equal level-FEXT (db) = 19.8
Power sum-ELFEXT (db) = 16.8
Power Sum-ELFEXT (db) = 16
Features
- Unshielded twisted pair
- Can be used in riser with raceway/fireproof shaft
- Meets or exceeds current Cat6 standards
- Length usage log on box to track remaining cable available for next job
Customer Reviews
Excellent cable.
Rollercoat
Rollercoat
Well made cable that did the job and fit the budget. Our new computers are humming along on the network now.
Very solid cable with just one flaw
msn yin yang
msn yin yang
The one flaw is that this cable is too thick for the boot I got. It was more than just a tight squeeze. I found some other cables from Home Depot that were CAT6 that fitted better. Very suitable for running across the ceiling in the basement to terminate into a panel. Not so suitable to have it terminate in a connector with a boot.
